Ex9BL-N 1P+N C6 100mA Wył. różn. z zabezp. nadpr., Icn=6kA, 1+Nbieg, char. C, In=6A, IΔn=100mA, typ AC
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 107659 |
GTIN(EAN) | 8592765076601 |
Price unit | piece |
Catalog price | 383,28 zł (311,61 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
ETIM class: | Earth leakage circuit breaker |
Number of poles (total): | 2 |
Number of protected poles: | 1 |
Rated voltage: | 230 V |
Rated current: | 6 A |
Rated fault current: | 0.1 A |
Leakage current type: | AC |
Current limiting class: | 3 |
Frequency: | 50/60 Hz |
Release characteristic: | C |
Concurrently switching neutral conductor: | yes |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 2 |
Built-in depth: | 77 mm |
Degree of protection (IP): | IP20 |
Surge current capacity: | 3 kA |
Voltage type: | AC |
Anti-nuisance tripping version: | no |
Rated insulation voltage Ui: | 500 V |
Rated impulse withstand voltage Uimp: | 4 kV |
Power loss: | 1.8 W |
