Ex9BL-H 1P+N B10 30mA Wył. różn. z zabezp. nadpr., Icn=10kA, 1+Nbieg. char. B, In=10A, IΔn=30mA, typ AC
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 107382 |
GTIN(EAN) | 8592765073839 |
Price unit | piece |
Catalog price | 289,16 zł (235,09 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
ETIM class: | Earth leakage circuit breaker |
Number of poles (total): | 2 |
Number of protected poles: | 1 |
Rated voltage: | 230 V |
Rated current: | 10 A |
Rated fault current: | 0.03 A |
Leakage current type: | AC |
Current limiting class: | 3 |
Frequency: | 50/60 Hz |
Release characteristic: | B |
Concurrently switching neutral conductor: | yes |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 2 |
Built-in depth: | 77 mm |
Degree of protection (IP): | IP20 |
Surge current capacity: | 3 kA |
Voltage type: | AC |
Anti-nuisance tripping version: | no |
Rated insulation voltage Ui: | 500 V |
Rated impulse withstand voltage Uimp: | 4 kV |
Power loss: | 2.5 W |
