Ex9UE1+2 100 NPE M Wkładka do Ex9UE1+2, 100 kA, N-PE
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 105496 |
GTIN(EAN) | 8592765054975 |
Price unit | piece |
Catalog price | 1 645,69 zł (1 337,96 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
ETIM class: | Combined arrester for power supply systems |
System configuration DC: | no |
System configuration IT: | yes |
System configuration TN: | yes |
System configuration TN-C: | no |
System configuration TN-C-S: | yes |
System configuration TN-S: | yes |
System configuration TT: | yes |
System configuration other: | no |
Number of poles: | 1 |
Lightning impulse current (10/350 µs): | 100 kA |
Max. continuous voltage AC: | 255 V |
Nominal voltage AC: | 255 V |
Voltage protection level L-N: | 1.5 kV |
Voltage protection level N-PE: | 1.5 kV |
Follow current extinguishing capability: | 100 kA |
Specific energy (W/R): | 2500 kJ/Ω |
Max. conductor cross section solid (solid, stranded): | 50 mm² |
Max. conductor cross section flexible (fine-strand): | 50 mm² |
Mounting method: | On basic element |
Construction size: | 2 modular spacing |
Remote signalling: | no |
Signalling at the device: | None |
Test class: | Type 1 + 2 |
Integrated backup fuse: | no |
Energy-coordinated protection effect with regard to the terminal equipment: | no |
Degree of protection (IP): | IP20 |
