Ex9B125 2P D100A Wył. nadpr. 20 kA, ch-ka D, 100 A, 2-bieg.
| Information | Value |
|---|---|
| Supplier | NOARK Electric Sp. z o.o. |
| Symbol | 102772 |
| GTIN(EAN) | 8592765027733 |
| Price unit | piece |
| Catalog price | 687,03 zł (558,56 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Additional features:
| Information | Value |
|---|---|
| Net weight: | 400 g |
| ETIM class: | Miniature circuit breaker (MCB) |
| Voltage type: | AC |
| Built-in depth: | 75 mm |
| Rated current: | 100 A |
| Rated voltage: | 400 V |
| Frequency: | 50 - 60 Hz |
| Release characteristic: | D |
| Rated insulation voltage Ui: | 690 V |
| Current limiting class: | 3 |
| Over voltage category: | 3 |
| Pollution degree: | 2 |
| Width in number of modular spacings: | 3 |
| Explosion-proof: | no |
| Power loss: | 15.4 W |
| Degree of protection (IP): | IP20 |
| Number of protected poles: | 2 |
| Concurrently switching neutral conductor: | no |
| Connectable conductor cross section solid-core: | 10 - 50 mm² |
| Ambient temperature during operating: | -30 - 70 °C |
| Flush-mounted installation: | no |
| Additional equipment possible: | yes |
| Number of poles (total): | 2 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 15 kA |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 15 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 20 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 20 kA |
| Rated impulse withstand voltage Uimp: | 8 kV |
