Ex9BN 1P B10 Wył. nadpr. 6 kA, ch-ka B, 10 A, 1-bieg.
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 100006 |
GTIN(EAN) | 8592765000071 |
Price unit | piece |
Catalog price | 21,16 zł (17,20 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Additional features:
Information | Value |
---|---|
Net weight: | 120 g |
ETIM class: | Miniature circuit breaker (MCB) |
Voltage type: | AC |
Built-in depth: | 72 mm |
Rated current: | 10 A |
Rated voltage: | 230 V |
Frequency: | 50 - 60 Hz |
Release characteristic: | B |
Rated insulation voltage Ui: | 690 V |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 1 |
Explosion-proof: | no |
Power loss: | 1.8 W |
Degree of protection (IP): | IP20 |
Number of protected poles: | 1 |
Concurrently switching neutral conductor: | no |
Connectable conductor cross section solid-core: | 1 - 35 mm² |
Ambient temperature during operating: | -30 - 70 °C |
Flush-mounted installation: | no |
Additional equipment possible: | yes |
Number of poles (total): | 1 |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 6 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 6 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 10 kA |
Rated impulse withstand voltage Uimp: | 6 kV |
