Rated ambient temperature according to IEC 62722-2-1:
-20 - 25 °C
With light source:
yes
With control gear:
yes
Dimming DMX:
no
Dimming DSI:
no
Dimming DALI:
no
Dimming 0-10 V:
no
Dimming 1-10 V:
no
Colour temperature:
4000 - 4000 K
Width:
85 mm
Rated luminous flux according to IEC 62722-2-1:
3200 lm
Height/depth:
92 mm
Colour rendering index CRI:
80-89
Dimming GPRS:
no
Lamp type:
LED not exchangeable
Rated life time L80/B10 at 25 °C:
50000 h
Dimming LineSwitch:
no
Dimming programmable:
no
Degree of protection (IP):
IP65
Energy efficiency class of the built-in lamp:
A++, A+, A (LED)
Protection class:
I
Max. system power:
27 W
Housing colour:
Grey
Beam angle:
Open beam/diffuse
Length:
1299 mm
Suitable for surface mounting:
yes
No dim function:
yes
Filament test according to IEC 60695-2-11:
650 °C - 30 s
Colour of light:
White
Suitable for emergency lighting:
yes
Suitable for wall mounting:
no
Suitable for ceiling mounting:
yes
Suitable for built-in mounting:
no
Material cover:
Plastic matt/satinized
Light distributor:
Diffuser lens/optic/panel
Voltage type:
AC
Suitable for light line configuration:
no
Suitable for suspended mounting:
yes
Light outlet:
Direct
Luminaire efficacy:
119 lm/W
Type of grid:
None
Type of wiring:
Suitable for through wiring
Type of control gear:
LED operating device current-controlled
Conductor cross section:
2.5 mm²
Nominal voltage:
220 - 240 V
Housing material:
Plastic
Light sharing:
Symmetric
Impact strength:
IK05
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
yes
