Przemiennik częstotliwości typu VT1, jednofazowe zasilanie 200...240VAC (50/60HZ). Wbudowany RS485. Wbudowany filtr EMC kat. C2, 0,2kW
Information | Value |
---|---|
Supplier | LOVATO Electric Sp. z o.o. |
Symbol | VT102A240 |
GTIN(EAN) | 8013975266182 |
Price unit | piece |
Catalog price | 1 198,02 zł (974,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 1,2 kg |
ETIM class: | Frequency converter =< 1 kV |
Number of phases input: | 1 |
Number of phases output: | 3 |
Type of converter: | U converter |
Mains frequency: | 50/60 Hz |
Degree of protection (IP): | IP20 |
Mains voltage: | 200 - 240 V |
Supporting protocol for BACnet: | yes |
Supporting protocol for SafetyBUS p: | no |
Supporting protocol for PROFIsafe: | no |
Supporting protocol for PROFINET IO: | no |
Supporting protocol for PROFINET CBA: | no |
Supporting protocol for Foundation Fieldbus: | no |
Supporting protocol for EtherNet/IP: | no |
Supporting protocol for DeviceNet Safety: | no |
Supporting protocol for AS-Interface Safety at Work: | no |
Application in domestic- and commercial area permitted: | no |
Application in industrial area permitted: | yes |
Integrated breaking resistance: | no |
4-quadrant operation possible: | no |
Supporting protocol for INTERBUS-Safety: | no |
Supporting protocol for SERCOS: | no |
With PC connection: | yes |
Supporting protocol for other bus systems: | yes |
Supporting protocol for SUCONET: | no |
Supporting protocol for DeviceNet: | no |
Supporting protocol for Data-Highway: | no |
Supporting protocol for Modbus: | yes |
Supporting protocol for KNX: | no |
Supporting protocol for INTERBUS: | no |
Supporting protocol for CAN: | no |
Supporting protocol for PROFIBUS: | no |
Supporting protocol for ASI: | no |
Supporting protocol for TCP/IP: | no |
With optical interface: | no |
Supporting protocol for LON: | no |
With control element: | yes |
Nominal output current I2N: | 1.8 A |
Max. output voltage: | 240 V |
Relative symmetric net frequency tolerance: | 10 % |
Relative symmetric net voltage tolerance: | 10 % |
Max. output at quadratic load at rated output voltage: | 0.2 kW |
Max. output at linear load at rated output voltage: | 0.2 kW |
Max. output frequency: | 599 Hz |
Number of interfaces PROFINET: | 0 |
Number of HW-interfaces USB: | 1 |
Number of HW-interfaces serial TTY: | 0 |
Number of HW-interfaces RS-485: | 1 |
Number of HW-interfaces RS-422: | 0 |
Number of HW-interfaces RS-232: | 0 |
Number of HW-interfaces industrial Ethernet: | 0 |
Number of analogue outputs: | 1 |
Number of analogue inputs: | 2 |
Number of digital outputs: | 1 |
Number of digital inputs: | 5 |
Depth: | 141 mm |
Height: | 72 mm |
Width: | 72 mm |
