Wyłącznik nadprądowy, 10kA - 3P - charakterystyka D, 8A
Information | Value |
---|---|
Supplier | LOVATO Electric Sp. z o.o. |
Symbol | P1MB3PD08 |
GTIN(EAN) | 8013975237601 |
Price unit | piece |
Catalog price | 260,76 zł (212,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 345 g |
ETIM class: | Miniature circuit breaker (MCB) |
Degree of protection (IP): | IP20 |
Release characteristic: | D |
Voltage type: | AC |
Ambient temperature during operating: | -40 - 70 °C |
Connectable conductor cross section solid-core: | 1 - 35 mm² |
Frequency: | 50 - 60 Hz |
Additional equipment possible: | yes |
Flush-mounted installation: | no |
Concurrently switching neutral conductor: | yes |
Explosion-proof: | no |
Rated impulse withstand voltage Uimp: | 4 kV |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 10 kA |
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 10 kA |
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 10 kA |
Number of poles (total): | 3 |
Number of protected poles: | 3 |
Width in number of modular spacings: | 3 |
Pollution degree: | 2 |
Over voltage category: | 3 |
Rated insulation voltage Ui: | 1000 V |
Rated voltage: | 400 V |
Rated current: | 8 A |
Built-in depth: | 66 mm |
