| Gross weight: |
950 g |
| ETIM class: |
Downlight/spot/floodlight
|
| Protection class: |
I |
| Width: |
66 mm |
| Reflector: |
None |
| Lamp holder: |
Other |
| Connection type: |
Other |
| Housing colour: |
Anthracite |
| Voltage type: |
AC |
| With movement sensor: |
yes |
| Suitable for lamp power: |
7.2 - 7.2 W |
| Type of control gear: |
LED operating device current-controlled |
| Colour rendering index CRI: |
80-89 |
| With light sensor: |
yes |
| Suitable for suspended mounting: |
no |
| Number of poles: |
2 |
| Length: |
201 mm |
| Height/depth: |
241 mm |
| Housing material: |
Aluminium |
| Lamp type: |
LED not exchangeable |
| Light outlet: |
Direct |
| Light sharing: |
Symmetric |
| Material cover: |
Plastic, transparent |
| Impact strength: |
IK03 |
| Nominal voltage: |
220 - 240 V |
| Degree of protection (IP): |
IP44 |
| With light source: |
yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: |
no |
| Covering of the luminaire with thermally insulating material possible: |
no |
| Suitable for built-in mounting: |
no |
| With control gear: |
yes |
| Suitable for workplace according to EN 12464-1: |
no |
| Suitable for surface mounting: |
yes |
| Beam angle: |
Extreme wide beam >80° |
| Connectable conductor cross section: |
1.5 - 1.5 mm² |
| Colour temperature: |
3000 - 3000 K |
| Max. system power: |
7.2 W |
| Rated luminous flux according to IEC 62722-2-1: |
648 lm |
| Colour of light: |
White |
| Adjustability: |
Not adjustable |
| Suitable for traverse mounting: |
no |
| Suitable for pedestal/floor mounting: |
no |
| Suitable for light-track mounting: |
no |
| Suitable for clamp-mounting: |
no |
| Luminous flux: |
648 - 648 lm |
| Type of wiring: |
Suitable for through wiring |
| Colour consistency (McAdam ellipse): |
SDCM3 |
| Photobiological safety according to EN 62471: |
Other |
| Rated ambient temperature according to IEC 62722-2-1: |
-20 - 40 °C |
| Filament test according to IEC 60695-2-11: |
650 °C - 30 s |
| LED nominal current at constant current: |
40 - 40 mA |
| Dimming 0-10 V: |
no |
| Dimming 1-10 V: |
no |
| Dimming DALI: |
no |
| Dimming DMX: |
no |
| Dimming potentiometer (integrated): |
no |
| Dimming GPRS: |
no |
| Dimming LineSwitch: |
no |
| Dimming manufacturer's proprietary system: |
no |
| Dimming mains voltage modulation: |
no |
| Dimming phase cut-off: |
no |
| Dimming phase cut-on: |
no |
| Dimming programmable: |
no |
| Dimming RF: |
no |
| Dimming Sine Wave Reduction: |
no |
| Dimming Touch and Dim: |
no |
| Dimming Zigbee: |
no |
| Dimming with push-button: |
no |
| No dim function: |
yes |
| Light distributor: |
None |
| Dimming depending on control gear: |
no |
| Luminaire efficacy: |
90 lm/W |
| Suitable for low voltage cable system: |
no |
| Dimming DSI: |
no |
| Energy efficiency class of the built-in lamp: |
A++, A+, A (LED) |
| Energy efficiency class of the provided exchangeable built-in lamp: |
A++ |
| Suitable for ceiling mounting: |
no |
| Power factor: |
0.9 |
