EPIC POWER M17 A1 6+PE F (5) Złącza
Information | Value |
---|---|
Supplier | Lapp Kabel Sp. z o.o. |
Symbol | 44423077 |
GTIN(EAN) | 4044776705093 |
Price unit | piece |
Catalog price | On demand |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
ETIM class: | Circular connector for field assembly (industrial connector) |
Rated voltage: | 630 V |
Housing material: | Zinc |
Pollution degree: | 3 |
Degree of protection (IP), mounted: | IP67 |
With protective conductor: | yes |
Contact type: | Bus |
Type of electric connection: | Crimp connection |
Material of contact surface: | Gold |
Rated current In: | 14 A |
Ambient temperature: | -40 - 125 °C |
Type of locking: | Gland nut |
Thread size M: | 17 mm |
Type of housing: | Straight |
Connectable conductor cross section solid-core: | 0.06 - 1.0 mm² |
Connectable conductor cross section fine-strand with cable end sleeve: | 0.06 - 1.0 mm² |
Connectable conductor cross section fine-strand without cable end sleeve: | 0.06 - 1.0 mm² |
Connectable conductor cross section multi-wired: | 0.06 - 1.0 mm² |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Limanowa,
ul. Tarnowska 9D
Distance:
Szaflary,
ul. Zakopiańska 18
Distance:
Gniezno,
ul. Słoneczna 40a
Distance:
Additional information:
Information | Value |
---|---|
Updated: | 2024-06-21 13:02:40 |
Files to download: | |
External links: |
