PIERŚCIEŃ ROZGAŁĘŹNY S-KSK 1 (10 szt.)
| Information | Value |
|---|---|
| Supplier | KOPOS Elektro Pl Sp. z o.o. |
| Symbol | S-KSK 1_KB |
| GTIN(EAN) | 8595568919656 |
| Price unit | piece |
| Catalog price | 22,13 zł (17,99 zł + 23% VAT) |
| Sale price | from 4,92 zł / szt. (4,00 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Rozgałęziająca się płytka zaciskowa składająca się z pięciu oddzielnych zacisków. Nadaje się do skrzynek KSK 80 i KSK 100.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 20 g |
| ETIM class: | Single- and multi-pole terminal strip |
| Explosion-tested version 'Ex e': | no |
| Connectable conductor cross section fine-strand without cable end sleeve: | 1,5 - 4 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve: | 1,5 - 4 mm² |
| Connectable conductor cross section solid-core: | 1,5 - 4 mm² |
| Connectable conductor cross section multi-wired: | 1,5 - 4 mm² |
| Rated current In: | 16 A |
| Rated voltage: | 500 V |
| Type of electrical connection 1: | Screw connection |
| Type of electrical connection 2: | Screw connection |
| Number of poles: | 5 |
| Number of clamp positions per pole: | 1 |
| Mounting method: | Direct mounting |
| Material insulation body: | Other |
| Operating temperature: | -40 - 85 °C |
| Inflammability class of insulation material according to with UL94: | V0 |
| Closing plate required: | no |
| Colour: | Grey |
| Transparent: | no |
buy at the outlet / on sale
Wholesaler / branch / Address
Distance
Available
Price
Actions
Bychowo-Hel Hurtownia Elektryczna o/Kwidzyn
Kwidzyn, Toruńska 34
Kwidzyn, Toruńska 34
Distance:
5 sztuk
4,92 zł/szt.
Wholesalers below does not have this product in their warehouses. You can anyway contact them and order it.
Order
Wholesaler
Address
Distance
Actions
Additional information:
| Information | Value |
|---|---|
| Manufacturer or importer or entity responsible in EU |
KOPOS KOLÍN a.s.
Havlíčkova 432, 280 02 Kolín, Czechy
tel: 420321730111 mail: kopos@kopos.cz
www: kopos.cz
|
| Updated: | 2025-01-14 10:26:09 |
| Files to download: |
|
