SPD Ogr. przepięć T1+T2 MOV 4P sieć TN-S/TT Iimp=50 kA In=50kA Up≤1,2kV styk
Information | Value |
---|---|
Supplier | HAGER POLO Sp. z o. o. (Berker) |
Symbol | SPA931 |
GTIN(EAN) | 3250615515186 |
Price unit | piece |
Catalog price | 1 814,25 zł (1 475,00 zł + 23% VAT) |
Promotions related to this product
-
Promocja Hager
Za zakup asortymentu firmy Hager odbierz jedną z nagród: organizer lub bluzę 4F.
-
Szybki print !
Przy zakupach marki HAGER za kwotę 5000 zł brutto w ElektRa Hurtownia Elektrotechniczna otrzymasz drukarkę XIAOMI Mi Portable Photo Printer !!
-
HAGER: Śrubokręt za zakup ogranicznika
Kup ogranicznik przepięć SPA931 marki HAGER i odbierz śrubokręt za 1 zł netto.
Additional features:
Information | Value |
---|---|
Gross weight: | 640 g |
ETIM class: | Combined arrester for power supply systems |
Max. conductor cross section solid (solid, stranded): | 35 mm² |
System configuration TN-S: | yes |
System configuration TT: | yes |
Voltage protection level L-N: | 1.2 kV |
Max. continuous voltage AC: | 335 V |
Mounting method: | DIN rail (top hat rail) 35 mm |
Voltage protection level L-PE: | 1.7 kV |
Voltage protection level N-PE: | 1.7 kV |
Integrated backup fuse: | no |
Voltage protection level: | 1.2 kV |
Construction size: | 4 modular spacing |
Lightning impulse current (10/350 µs): | 12.5 kA |
Signalling at the device: | Optical |
System configuration IT: | no |
Max. conductor cross section flexible (fine-strand): | 25 mm² |
System configuration TN: | no |
Specific energy (W/R): | 15 kJ/Ω |
Number of poles: | 4 |
System configuration other: | no |
Nominal voltage AC: | 415 V |
System configuration DC: | no |
System configuration TN-C: | no |
System configuration TN-C-S: | yes |
Degree of protection (IP): | IP20 |
Remote signalling: | yes |
Test class: | Type 1 + 2 |
Max. overcurrent protection device, parallel connection (fuse): | 160 A |
Max. overcurrent protection device, series connection (fuse): | 80 A |
Voltage switching spark gap technology: | yes |
Energy-coordinated protection effect with regard to the terminal equipment: | yes |
