SPD Ogr. przepięć T1+T2 MOV 3P sieć TN-C Iimp=37,5kA In=50kA Up≤1,2kV styk
Information | Value |
---|---|
Supplier | HAGER POLO Sp. z o. o. (Berker) |
Symbol | SPA930 |
GTIN(EAN) | 3250615515179 |
Price unit | piece |
Catalog price | 1 568,25 zł (1 275,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
-
Promocja Hager
Za zakup asortymentu firmy Hager odbierz jedną z nagród: organizer lub bluzę 4F.
-
Szybki print !
Przy zakupach marki HAGER za kwotę 5000 zł brutto w ElektRa Hurtownia Elektrotechniczna otrzymasz drukarkę XIAOMI Mi Portable Photo Printer !!
Additional features:
Information | Value |
---|---|
Gross weight: | 524 g |
ETIM class: | Combined arrester for power supply systems |
Max. conductor cross section solid (solid, stranded): | 35 mm² |
System configuration TN-S: | no |
System configuration TT: | no |
Voltage protection level L-N: | 1.2 kV |
Max. continuous voltage AC: | 335 V |
Mounting method: | DIN rail (top hat rail) 35 mm |
Voltage protection level L-PE: | 1.7 kV |
Voltage protection level N-PE: | 1.7 kV |
Integrated backup fuse: | no |
Voltage protection level: | 1.2 kV |
Construction size: | 3 modular spacing |
Lightning impulse current (10/350 µs): | 12.5 kA |
Signalling at the device: | Optical |
System configuration IT: | no |
Max. conductor cross section flexible (fine-strand): | 25 mm² |
System configuration TN: | no |
Number of poles: | 3 |
System configuration other: | no |
Nominal voltage AC: | 415 V |
System configuration DC: | no |
System configuration TN-C: | yes |
System configuration TN-C-S: | no |
Degree of protection (IP): | IP20 |
Remote signalling: | yes |
Test class: | Type 1 + 2 |
Max. overcurrent protection device, parallel connection (fuse): | 160 A |
Max. overcurrent protection device, series connection (fuse): | 80 A |
Voltage switching spark gap technology: | yes |
