Zasilacz impulsowy, 78.51.1.230.1203
| Information | Value |
|---|---|
| Supplier | FINDER Polska Sp. z o.o. |
| Symbol | 785112301203 |
| GTIN(EAN) | 8012823402871 |
| Price unit | piece |
| Catalog price | 578,87 zł (470,63 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 184 g |
| ETIM class: | DC-power supply |
| Power consumption: | 89 VA |
| Width: | 70 mm |
| Height: | 85.3 mm |
| Max. output current 1: | 4.6 A |
| Nominal value output voltage 1: | 12 V |
| Nominal value output current 1: | 4.2 A |
| Power output: | 50 W |
| Width in number of modular spacings: | 4 |
| Depth: | 56.5 mm |
| Output voltage stabilized: | yes |
| Wall mounting possible: | no |
| Stabilized: | yes |
| Suitable for safety functions: | no |
| Modular version: | yes |
| Rail mounting possible: | yes |
| Short-circuit-proof: | yes |
| Secondary voltage adjustable: | no |
| 1st secondary output voltage: | 12 - 15 V |
| Rated supply voltage AC 50 Hz: | 110 - 240 V |
| Rated supply voltage AC 60 Hz: | 110 - 240 V |
| Rated supply voltage DC: | 220 - 220 V |
| Degree of protection (IP): | IP20 |
| Type of electric connection: | Screw connection |
| SIL according to IEC 61508: | None |
| Performance level according to EN ISO 13849-1: | None |
| Voltage type (supply voltage): | AC/DC |
