Ściemniacz uniwersalny (R, L, C, ESL); 1 moduł montaż na szynie DIN, zasilanie 230V AC (R) 500 W
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | SCO |
| Symbol | SCO-815 |
| GTIN(EAN) | 5908312596684 |
| Price unit | piece |
| Catalog price | 249,69 zł (203,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Napięcie zasilania 230 V AC Element wykonawczy tranzystor Pamięć stanu po zaniku zasilania NIE Maksymalna moc podłączonych żarówek R/L/C - 500W ; ESL/LED - 100W Napięcie sterowania 8÷230V AC/DC Zastosowanie oświetlenie żarowe, halogenowe, LED (ściemnalne), świetlówki (ściemnalne) Sterownie obciążeniem załączanie lub wyłączanie w 0 (obciążenia uniwersalne) Pamięć stanu TAK Instalacja 3-przewodowa Przyłącze zaciski śrubowe 2,5 mm² Moment dokręcający 0,4 Nm Pobór mocy 0,1 W Temperatura pracy -25 ÷ 50 °C Wymiary 1 moduł (18 mm) Montaż na szynie 35 mm Stopień ochrony IP20
Additional features:
| Information | Value |
|---|---|
| ETIM class: | Dimmer |
| Assembly arrangement: | Basic element |
| Method of operation: | Push button |
| Serial dimmer: | no |
| Type of load: | Resistive load |
| Substation input: | no |
| Light value memory: | yes |
| Applicable with button: | yes |
| Applicable with movement sensor: | no |
| Applicable with presence indicator: | no |
| Applicable with time switch/timer: | no |
| Applicable with transmission button: | no |
| Applicable with infrared button: | no |
| Type of fastening: | Mounting with screw |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen free: | yes |
| Transparent: | no |
| Suitable for degree of protection (IP): | IP20 |
| Frequency: | 50 - 50 Hz |
| Device width: | 18 mm |
| Device depth: | 65 mm |
