ZJUD-VAR24V (2 SZT.) ZŁĄCZKA
| Information | Value |
|---|---|
| Supplier | ERGOM Zakład Aparatury Elektrycznej Sp. z o.o. |
| Symbol | R34RR-07030010822 |
| Price unit | piece |
| Catalog price | 32,67 zł (26,56 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| ETIM class: | Component terminal block |
| Explosion-tested version 'Ex e': | no |
| Connectable conductor cross section fine-strand without cable end sleeve: | 0.2 - 2.5 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve: | 0.2 - 2.5 mm² |
| Connectable conductor cross section solid-core: | 0.2 - 4 mm² |
| Rated current In: | 32 A |
| Rated voltage: | 24 V |
| Type of electrical connection 1: | Screw connection |
| Type of electrical connection 2: | Screw connection |
| Number of levels: | 2 |
| Number of clamp positions per level: | 2 |
| Internally connected stages: | no |
| Mounting method: | DIN rail (top hat rail) 35 mm |
| Material insulation body: | Other |
| Operating temperature: | -25 - 55 °C |
| Inflammability class of insulation material according to with UL94: | V0 |
| Closing plate required: | no |
| Colour: | Grey |
| Type of component: | Varistor (voltage-sensitive resistor) |
