ZJUN-150 (5 SZT.) ZŁĄCZKA
Information | Value |
---|---|
Supplier | ERGOM Zakład Aparatury Elektrycznej Sp. z o.o. |
Symbol | R34RR-07010001903 |
Price unit | piece |
Catalog price | 34,28 zł (27,87 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
ETIM class: | Panel feed-through terminal block |
Connectable conductor cross section fine-strand without cable end sleeve: | 35 - 150 mm² |
Connectable conductor cross section solid-core: | 35 - 150 mm² |
Connectable conductor cross section multi-wired: | 35 - 150 mm² |
Rated current In: | 320 A |
Rated voltage: | 1000 V |
Type of electrical connection 1: | Screw connection |
Connection position: | Atop |
Number of poles: | 1 |
Number of clamp positions per pole: | 2 |
Mounting method: | DIN rail (top hat rail) 35 mm |
Material insulation body: | Thermoplastic |
Operating temperature: | -40 - 100 °C |
Inflammability class of insulation material according to with UL94: | V0 |
Explosion-tested version 'Ex e': | no |
Closing plate required: | no |
Colour: | Grey |
With integrated feed-through flange: | no |
Connectable conductor cross section fine-strand with cable end sleeve: | 35 - 150 mm² |
Type of electrical connection 2: | Screw connection |
Width/grid dimension: | 29 mm |
