Z-PUL24/SS Przycisk
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | 276295 |
| GTIN(EAN) | 4015082762957 |
| Price unit | piece |
| Catalog price | 194,83 zł (158,40 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Przycisk z diodą, funkcja: 2 zestyków zwiernych, znamionowy prąd pracy 16A, znamionowe napięcie pracy przełącznika 250 V AC, znamionowe napięcie pracy LED 24V AC/DC, kolor przycisku zielony, kolor LED pomarańczowy, wymiary montażowe zatyczki 45mm, szerokość montażowa 1JC (17,5mm), wyłącznik naprądowy, przekrój zacisku 1-10 mm², wersja zgodna z IEC/EN 60669, VDE 0632
Additional features:
| Information | Value |
|---|---|
| Net weight: | 80 g |
| ETIM class: | Push button for distribution board |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 2 |
| Number of contacts as change-over contact: | 0 |
| Switching current: | 16 A |
| Switching voltage: | 250 V |
| Voltage type: | AC |
| With signal lamp: | yes |
| Colour calotte: | Other |
| Lamp type: | LED |
| Lamp socket: | Other |
| Max. lamp power: | 2 W |
| Lamp voltage: | 12 - 24 V |
| Colour button: | Green |
| Width in number of modular spacings: | 1 |
| Built-in depth: | 60 mm |
| Degree of protection (IP): | IP40 |
