NZM1-XUHIV20L110-130AC Wyzwalacz zanikowy z 2 stykami wyprz.
Information | Value |
---|---|
Supplier | EATON Electric Sp. z o.o. (MOELLER) |
Symbol | 259620 |
GTIN(EAN) | 4015082596200 |
Price unit | piece |
Catalog price | 1 121,27 zł (911,60 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: for interlocking and load-shedding circuits, as well as for early-make of the undervoltage release in main-switch applications. For use with Emergency-Stop devices in conjunction with emergency-stop button. when the shunt release is energized, accidental contact with the main contacts of the switch during attempts to switch on is safely prevented . Early make of auxiliary contacts on switching on and off (manual operation): approx. 20ms. Cannot be used in conjunction with NZM...-XR.. remote operator. Undervoltage releases cannot be installed simultaneously with NZM..-XHIV.. early-make auxiliary contact or NZM..-XA.. shunt release. Can be used for: NZM1(-4), N(N/O)1(-4)
Additional features:
Information | Value |
---|---|
Net weight: | 170 g |
ETIM class: | Under voltage coil |
Rated control supply voltage AC 50 Hz: | 110 - 130 V |
Rated control supply voltage AC 60 Hz: | 110 - 130 V |
Rated control supply voltage DC: | 0 - 0 V |
Voltage type for actuating: | AC |
Type of electric connection: | Screw connection |
Number of contacts as normally open contact: | 2 |
Number of contacts as normally closed contact: | 0 |
Number of contacts as change-over contact: | 0 |
Delayed: | no |
Suitable for power circuit breaker: | no |
Suitable for off-load switch: | yes |
Suitable for motor safety switch: | no |
Suitable for overload relay: | no |
