CKN6-20/1N/C/003-DE Wył.nadpr. z mod. różnic., 1+N-bieg.

• buy at the outlet / on sale
• Buy / order

Information	Value
Supplier	EATON Electric Sp. z o.o. (MOELLER)
Symbol	241425
GTIN(EAN)	4015082414252
Price unit	piece
Product withdrawn	This product is not produced any more. It might still be available if some wholesaler has it in it's stock

Additional features:

Information	Value
Net weight:	203 g
ETIM class:	Earth leakage circuit breaker
Number of poles (total):	2
Number of protected poles:	1
Rated insulation voltage Ui:	250 V
Rated impulse withstand voltage Uimp:	4 kV
Rated current:	20 A
Rated fault current:	0.03 A
Leakage current type:	AC
Current limiting class:	3
Rated short-circuit breaking capacity according to EN 61009:	6 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1:	6 kA
Surge current capacity:	0.25 kA
Voltage type:	AC
Frequency:	50 Hz
Release characteristic:	C
Concurrently switching neutral conductor:	yes
With interlocking device:	no
Over voltage category:	3
Pollution degree:	2
Ambient temperature during operating:	-25 - 40 °C
Width in number of modular spacings:	2
Built-in depth:	69.5 mm
Anti-nuisance tripping version:	no
Degree of protection (IP):	IP20
Connectable conductor cross section solid-core:	1 - 25 mm²
Connectable conductor cross section multi-wired:	1 - 25 mm²

Additional information:

Information	Value
Updated:	2022-12-04 14:34:22
External links:	Głęboki link do str. produktu
