CKN6-10/1N/C/003-A-DE Wył.nadpr. z mod. różnic., 1+N-bieg.

Information Value
Supplier EATON Electric Sp. z o.o. (MOELLER)
Symbol 241334
GTIN(EAN) 4015082413347
Price unit piece
Product withdrawn This product is not produced any more. It might still be available if some wholesaler has it in it's stock
Sale price from 99,56 zł (80,94 zł + 23 % VAT)
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.

Additional features:

Information Value
ETIM class: Earth leakage circuit breaker
Number of poles (total): 2
Number of protected poles: 1
Rated voltage: 230 V
Rated insulation voltage Ui: 250 V
Rated impulse withstand voltage Uimp: 4 kV
Rated current: 10 A
Rated fault current: 0.03 A
Leakage current type: A
Current limiting class: 3
Rated short-circuit breaking capacity according to EN 61009: 6 kA
Rated short-circuit breaking capacity according to IEC 60947-2: 0 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1: 6 kA
Surge current capacity: 0.25 kA
Voltage type: AC
Frequency: 50 Hz
Release characteristic: C
Concurrently switching neutral conductor: yes
With interlocking device: no
Over voltage category: 3
Pollution degree: 2
Ambient temperature during operating: -25 - 40 °C
Width in number of modular spacings: 2
Built-in depth: 69.5 mm
Anti-nuisance tripping version: no
Degree of protection (IP): IP20
Connectable conductor cross section solid-core: 1 - 25 mm²
Connectable conductor cross section multi-wired: 1 - 25 mm²
