AZ-4-C32 Wyłącznik nadprądowy 25kA, In= 32A, char. C, 4-bieg. Seria AZ
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | 211782 |
| GTIN(EAN) | 4015082117825 |
| Price unit | piece |
| Catalog price | 2 441,55 zł (1 985,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Wyłącznik ochronny, 1-biegunowy, prąd znamionowy 32A, charakterystyka wyzwolenia C, znamionowe napięcie pracy 230/400V, znamionowa zdolność łączenia według IEC/EN 60947-2: 25kA, wymiary montażowe zatyczki 45mm, wyłącznik naprądowy, przekrój zacisku 2,5-50 mm² jednożyłowy
Additional features:
| Information | Value |
|---|---|
| Net weight: | 906 g |
| ETIM class: | Miniature circuit breaker (MCB) |
| Built-in depth: | 75 mm |
| Release characteristic: | C |
| Number of poles (total): | 4 |
| Number of protected poles: | 4 |
| Rated current: | 32 A |
| Rated voltage: | 400 V |
| Rated insulation voltage Ui: | 440 V |
| Rated impulse withstand voltage Uimp: | 4 kV |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: | 0 kA |
| Voltage type: | AC |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: | 0 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: | 25 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: | 25 kA |
| Frequency: | 50 - 60 Hz |
| Current limiting class: | 3 |
| Flush-mounted installation: | no |
| Concurrently switching neutral conductor: | yes |
| Over voltage category: | 3 |
| Pollution degree: | 2 |
| Additional equipment possible: | yes |
| Width in number of modular spacings: | 6 |
| Degree of protection (IP): | IP20 |
| Ambient temperature during operating: | -25 - 55 °C |
| Connectable conductor cross section multi-wired: | 2.5 - 50 mm² |
| Connectable conductor cross section solid-core: | 2.5 - 50 mm² |
| Explosion-proof: | no |
