Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V:
6 kA
Voltage type:
AC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V:
6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V:
10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V:
10 kA
Frequency:
50 - 60 Hz
Current limiting class:
3
Flush-mounted installation:
no
Concurrently switching neutral conductor:
yes
Over voltage category:
3
Pollution degree:
2
Additional equipment possible:
yes
Width in number of modular spacings:
4
Degree of protection (IP):
IP20
Ambient temperature during operating:
-25 - 75 °C
Connectable conductor cross section multi-wired:
1 - 25 mm²
Connectable conductor cross section solid-core:
1 - 25 mm²
Explosion-proof:
no
