RS2-02-C3 RS2, 2NC Magn. wył. bezp.., 3m
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | 177286 |
| GTIN(EAN) | 4015081717392 |
| Price unit | piece |
| Catalog price | 920,66 zł (748,50 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Non-contacting safety switch, switching distance according to IEC 60947-5-2, SL up to Ple ISO 13849, SL up zo SIL3 according to IEC 62061, 2NC, 3m cable
Additional features:
| Information | Value |
|---|---|
| Net weight: | 182 g |
| ETIM class: | Position switch with separate actuator |
| Suitable for safety functions: | yes |
| Width sensor: | 26 mm |
| Height of sensor: | 13 mm |
| Length of sensor: | 52 mm |
| Number of safety auxiliary contacts: | 2 |
| Number of contacts as normally closed contact: | 2 |
| Number of contacts as normally open contact: | 0 |
| Number of contacts as change-over contact: | 0 |
| Type of switching contact: | Other |
| Rated operation current Ie at AC-15, 24 V: | 0 A |
| Rated operation current Ie at AC-15, 125 V: | 0 A |
| Rated operation current Ie at AC-15, 230 V: | 0 A |
| Rated operation current Ie at DC-13, 24 V: | 0.3 A |
| Rated operation current Ie at DC-13, 125 V: | 0 A |
| Rated operation current Ie at DC-13, 230 V: | 0 A |
| Construction type housing: | Cuboid |
| Housing material: | Plastic |
| Coating housing: | Plastic-coated |
| Type of interface: | None |
| Type of interface for safety communication: | None |
| Type of electric connection: | With cable preassembled |
| Explosion safety category for gas: | None |
| Explosion safety category for dust: | None |
| Ambient temperature during operating: | -10 - 55 °C |
| Degree of protection (IP): | IP67 |
| Degree of protection (NEMA): | Other |
