FRBMM-C25/2/03 Wyłącznik kombinowany 10kA serii FRBmM
Information | Value |
---|---|
Supplier | EATON Electric Sp. z o.o. (MOELLER) |
Symbol | 170858 |
GTIN(EAN) | 4015081674190 |
Price unit | piece |
Catalog price | 1 138,00 zł (925,20 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 250 g |
ETIM class: | Earth leakage circuit breaker |
Voltage type: | AC |
Built-in depth: | 75.5 mm |
Rated current: | 25 A |
Rated voltage: | 240 V |
Release characteristic: | C |
Rated insulation voltage Ui: | 500 V |
Rated fault current: | 0.3 A |
Leakage current type: | AC |
Surge current capacity: | 0.25 kA |
Current limiting class: | 3 |
Over voltage category: | 3 |
Pollution degree: | 2 |
Width in number of modular spacings: | 2 |
Frequency: | 50 Hz |
Degree of protection (IP): | IP20 |
Number of protected poles: | 2 |
Concurrently switching neutral conductor: | no |
Rated short-circuit breaking capacity according to IEC 60947-2: | 0 kA |
Connectable conductor cross section solid-core: | 1 - 25 mm² |
Connectable conductor cross section multi-wired: | 1 - 25 mm² |
With interlocking device: | no |
Ambient temperature during operating: | -25 - 40 °C |
Flush-mounted installation: | no |
Number of poles (total): | 2 |
Anti-nuisance tripping version: | no |
Rated impulse withstand voltage Uimp: | 4 kV |
Rated short-circuit breaking capacity Icn according to EN 61009-1: | 10 kA |
Disconnection characteristic: | Undelayed |
Rated short-circuit breaking capacity according to EN 61009: | 10 kA |
