LN1-4-63-I Rozłącznik mocy LN1 ,4-bieg., 63A
Information | Value |
---|---|
Supplier | EATON Electric Sp. z o.o. (MOELLER) |
Symbol | 111998 |
GTIN(EAN) | 4015081115464 |
Price unit | piece |
Catalog price | 1 405,89 zł (1 143,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 1,15 kg |
Country of origin | Rumunia |
ETIM class: | Switch disconnector (low voltage) |
Width: | 120 mm |
Height: | 145 mm |
Depth: | 88 mm |
Rated operation power at AC-3, 400 V: | 0 kW |
Number of auxiliary contacts as normally open contact: | 0 |
Number of auxiliary contacts as normally closed contact: | 0 |
Rated permanent current Iu: | 63 A |
Number of poles: | 4 |
Rated operating voltage: | 690 - 690 V |
Conditioned rated short-circuit current Iq: | 100 kA |
Degree of protection (IP), front side: | IP20 |
Number of auxiliary contacts as change-over contact: | 0 |
Interlockable: | yes |
Motor drive integrated: | no |
Type of electrical connection of main circuit: | Frame clamp |
Version as emergency stop installation: | yes |
Type of control element: | Rocker lever |
Version as main switch: | yes |
Version as safety switch: | no |
Version as maintenance-/service switch: | yes |
Rated operation power at AC-23, 400 V: | 30 kW |
Rated short-time withstand current lcw: | 2 kA |
Colour control element: | Grey |
Suitable for floor mounting: | yes |
Suitable for front mounting 4-hole: | no |
Suitable for front mounting centre: | no |
Suitable for distribution board installation: | yes |
Suitable for intermediate mounting: | yes |
Max. rated operation voltage Ue AC: | 400 V |
Motor drive optional: | yes |
Voltage release optional: | yes |
Device construction: | Built-in device fixed built-in technique |
Rated permanent current at AC-21, 400 V: | 0 A |
Switching power at 400 V: | 0 kW |
Version as reversing switch: | no |
With pre-assembled cabling: | no |
