EQ96S-600/5 ; Amperomierz, klasa 1,5, do pracy z przek
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | 083668 |
| GTIN(EAN) | 4015080836681 |
| Price unit | piece |
| Product withdrawn | This product is not produced any more. It might still be available if some wholesaler has it in it's stock |
| Sale price | from 176,86 zł / szt. (143,79 zł + 23 % VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Amperomierz, klasa 1.5 do montażu drzwi, analogowy, WxS=96x96mm, zakres pomiarowy=0-600A, wg DIN 43780 i DIN VDE 410, obudowa DIN 43700, rama wąska DIN 43718, skala kwadrantowa DIN 43802 z ustawieniem zgrubnym-precyzyjnym, przyłącza zabezpieczone przed dotknięciem, pionowe położenie użytkowe, do przyłącza przemiennika=5A, pobór mocy 0.7VA, ekranowany 4mT, z mocowaniem zatrzaskowym
Additional features:
| Information | Value |
|---|---|
| ETIM class: | Ampere meter for installation |
| Nominal end value of the scale: | 600 A |
| Measuring range: | 0 - 600 A |
| Transformer connection: | yes |
| Accuracy class: | 1.5 |
| Power loss: | 0.7 W |
| Voltage type: | AC |
| Overcurrent scale: | no |
| Model: | Built-in |
| Modular version: | no |
| Width: | 96 mm |
| Height: | 96 mm |
| Width in number of modular spacings: | 0 |
| Max. needle deflection: | 90 ° |
| Measurement system: | Soft iron |
| Stay-set indicator: | no |
| Scales lighting: | no |
