WYŁĄCZNIK RÓŻNICOWOPRĄDOWY AC 4P 25A 30mA
| Information | Value |
|---|---|
| Supplier | BEMKO Sp. z o.o. |
| Series | N7 |
| Symbol | S-A05-N7-4-25-030 |
| GTIN(EAN) | 5908311361887 |
| Price unit | piece |
| Catalog price | 154,98 zł (126,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 440 g |
| ETIM class: | Residual current circuit breaker (RCCB) |
| Number of poles: | 4 |
| Rated voltage: | 230 V |
| Rated current: | 25 A |
| Rated fault current: | 0.3 A |
| Rated insulation voltage Ui: | 300 V |
| Rated impulse withstand voltage Uimp: | 4 kV |
| Mounting method: | DIN rail |
| Leakage current type: | AC |
| Selective protection: | no |
| Short-time delayed tripping: | no |
| Short-circuit breaking capacity (Icw): | 6 kA |
| Surge current capacity: | 3 kA |
| With interlocking device: | no |
| Frequency: | 50/60 Hz |
| Additional equipment possible: | no |
| Degree of protection (IP): | IP20 |
| Width in number of modular spacings: | 4 |
| Built-in depth: | 50 mm |
| Ambient temperature during operating: | -5 - 40 °C |
| Pollution degree: | 2 |
| Connectable conductor cross section multi-wired: | 5 - 16 mm² |
| Connectable conductor cross section solid-core: | 5 - 25 mm² |
