Stycznik EK550-40-11 220-230V 50Hz AC
| Information | Value |
|---|---|
| Supplier | ABB Sp. z o.o. (NN) |
| Symbol | SK827041-EM |
| GTIN(EAN) | 7320500025598 |
| Price unit | piece |
| Catalog price | 17 719,64 zł (14 406,21 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 15,5 kg |
| ETIM class: | Power contactor, AC switching |
| Rated control supply voltage AC 50 Hz: | 220 - 230 V |
| Rated control supply voltage AC 60 Hz: | 230 - 255 V |
| Voltage type for actuating: | AC |
| Rated operation current Ie at AC-1, 400 V: | 800 A |
| Rated operation current Ie at AC-3, 400 V: | 550 A |
| Modular version: | no |
| Number of auxiliary contacts as normally open contact: | 1 |
| Number of auxiliary contacts as normally closed contact: | 1 |
| Type of electrical connection of main circuit: | Rail connection |
| Number of normally open contacts as main contact: | 4 |
| Number of normally closed contacts as main contact: | 0 |
| Rated operation power at AC-3, 400 V: | 280 kW |
| Width: | 270 mm |
| Height: | 272 mm |
| Depth: | 225.5 mm |
