Moduł ESP415M4
| Information | Value |
|---|---|
| Supplier | ABB Sp. z o.o. (NN) |
| Symbol | 7TCA085460R0124 |
| GTIN(EAN) | 5414363168980 |
| Price unit | piece |
| Catalog price | 27 290,38 zł (22 187,30 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 3,9 kg |
| ETIM class: | Surge protection device for power supply systems |
| Mounting method: | Other |
| Construction size: | Other |
| Signalling at the device: | Optical |
| Degree of protection (IP): | IP20 |
| With remote signalling contact: | no |
| Number of conductors (without earthing): | 4 |
| Voltage protection level: | 0.9 kV |
| Max. continuous voltage AC: | 280 V |
| Nominal discharge surge current (8/20): | 80 kA |
| Nominal voltage AC: | 250 V |
| Category type 2: | yes |
| Voltage protection level L-N: | 0.9 kV |
| Voltage protection level N-PE: | 0.9 kV |
| Integrated backup fuse: | yes |
| Max. conductor cross section solid (solid, stranded): | 50 mm² |
| Max. conductor cross section flexible (fine-strand): | 50 mm² |
| System configuration DC: | no |
| System configuration IT: | no |
| System configuration TN: | yes |
| System configuration TN-C: | yes |
| System configuration TN-S: | yes |
| System configuration TT: | no |
| System configuration other: | no |
| System configuration TN-C-S: | yes |
| Max. discharge surge current (8/20): | 150 kA |
| Short-circuit breaking capacity (Isccr): | 25 kA |
