Moduł ESP240-5A/BX
Information | Value |
---|---|
Supplier | ABB Sp. z o.o. (NN) |
Symbol | 7TCA085460R0084 |
GTIN(EAN) | 5414363086314 |
Price unit | piece |
Catalog price | 1 449,46 zł (1 178,42 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 230 g |
ETIM class: | Surge protection device for terminal equipment |
Mounting method: | Screwable |
Signalling at the device: | None |
Degree of protection (IP): | IP66 |
With remote signalling contact: | no |
Number of poles: | 1 |
Voltage protection level: | 0.79 kV |
Max. continuous voltage AC: | 280 V |
Total discharge current (8/20) (L+N-PE): | 10 kA |
Nominal discharge surge current (8/20) (L-N): | 5 kA |
Nominal load current: | 5 A |
Nominal voltage AC: | 240 V |
Category type 3: | yes |
Voltage protection level L-N: | 0.79 kV |
Voltage protection level L-PE/N-PE: | 0.79 kV |
With interference suppressor filter: | yes |
Max. conductor cross section solid (solid, stranded): | 4 mm² |
Max. conductor cross section flexible (fine-strand): | 4 mm² |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
