DSH201 B6 AC30 wyłącznik różnicowo-nadprądowy | 1P+N | char. B | 6A | 6kA | 30mA | AC | bezzwłoczny |
Information | Value |
---|---|
Supplier | ABB Sp. z o.o. (NN) |
Symbol | 2CSR255070R1065 |
GTIN(EAN) | 8012542344018 |
Price unit | piece |
Catalog price | 352,73 zł (286,77 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 182 g |
ETIM class: | Earth leakage circuit breaker |
Number of poles (total): | 2 |
Number of protected poles: | 1 |
Rated voltage: | 230 V |
Rated current: | 6 A |
Leakage current type: | AC |
Rated short-circuit breaking capacity according to EN 61009: | 6 kA |
Rated short-circuit breaking capacity according to IEC 60947-2: | 10 kA |
Voltage type: | AC |
Frequency: | 50 Hz |
Release characteristic: | B |
Concurrently switching neutral conductor: | yes |
With interlocking device: | yes |
Pollution degree: | 2 |
Ambient temperature during operating: | -25 - 55 °C |
Width in number of modular spacings: | 2 |
Built-in depth: | 69 mm |
Flush-mounted installation: | yes |
Anti-nuisance tripping version: | yes |
Degree of protection (IP): | IP2X |
Over voltage category: | 3 |
Surge current capacity: | 0 kA |
