PS4/36/16H-DDA204 Szyna mostkująca
| Information | Value |
|---|---|
| Supplier | ABB Sp. z o.o. (NN) |
| Symbol | 2CDL041204R1636 |
| GTIN(EAN) | 4016779652612 |
| Price unit | piece |
| Catalog price | 882,88 zł (717,79 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 697 g |
| ETIM class: | Phase busbar |
| Number of phases: | 4 |
| Number of poles: | 36 |
| Suitable for number of devices: | 9 |
| Module width: | 17.5 mm |
| Cross section: | 16 mm² |
| Length: | 985 mm |
| Width in number of modular spacings: | 56 |
| Rated permanent current Iu: | 63 A |
| Type of electric connection: | Pin |
| Insulated: | yes |
| Max. rated operation voltage Ue: | 690 V |
| Rated short-time withstand current lcw: | 25 kA |
| Suitable for devices with N-conductor: | yes |
| Suitable for devices with auxiliary switch: | yes |
| Colour: | Grey |
