Adjustment range short-term delayed short-circuit release:
480.0 - 8000 A
Adjustment range undelayed short-circuit release:
800 - 8000 A
Integrated earth fault protection:
no
Type of electrical connection of main circuit:
Bolt connection
Device construction:
Built-in device fixed built-in technique
Suitable for DIN rail (top hat rail) mounting:
no
DIN rail (top hat rail) mounting optional:
no
With switched-off indicator:
no
With integrated under voltage release:
no
Number of poles:
3
Position of connection for main current circuit:
Front side
Type of control element:
Toggle
Complete device with protection unit:
yes
Motor drive integrated:
no
Motor drive optional:
yes
Degree of protection (IP):
IP20
Number of auxiliary contacts as normally closed contact:
0
Number of auxiliary contacts as normally open contact:
0
Number of auxiliary contacts as change-over contact:
0
