E4.2/MT 3200 MP 4p Earth DOWN uziemnik
Information | Value |
---|---|
Supplier | ABB Sp. z o.o. (NN) |
Symbol | 1SDA081789R1 |
GTIN(EAN) | 8015644883560 |
Price unit | piece |
Catalog price | 89 670,57 zł (72 902,90 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 136 kg |
ETIM class: | Power circuit-breaker for trafo/generator/installation protection |
Rated permanent current Iu: | 3200 A |
Overload release current setting: | 1280.0 - 3200 A |
Adjustment range undelayed short-circuit release: | 4800.0 - 48000 A |
Integrated earth fault protection: | no |
Type of electrical connection of main circuit: | Connection at separate chassis part |
Device construction: | Built-in device slide-in technique (withdrawable) |
Suitable for DIN rail (top hat rail) mounting: | no |
DIN rail (top hat rail) mounting optional: | no |
Number of auxiliary contacts as change-over contact: | 4 |
With switched-off indicator: | yes |
With integrated under voltage release: | no |
Number of poles: | 4 |
Position of connection for main current circuit: | Connection at separate chassis part |
Type of control element: | Push button |
Complete device with protection unit: | yes |
Motor drive integrated: | no |
Motor drive optional: | yes |
Degree of protection (IP): | IP30 |
Rated voltage: | 690 - 690 V |
Number of auxiliary contacts as normally closed contact: | 0 |
Number of auxiliary contacts as normally open contact: | 0 |
Unfortunately, this product is not available in any warehouse of any wholesaler of the EL-Plus group. However, you can contact the wholesaler of your choice and order it.
Order
Wholesaler
Address
Distance
Actions
Firma Handlowa "ELEKTRET" Spółka komandytowa Jacek Bieda, Agata Mól
Limanowa,
ul. Tarnowska 9D
Distance:
Firma Handlowo-Usługowa "LUX-SYSTEM" S.M. Stanek, J.E. Poniedziałek Sp.j.
Szaflary,
ul. Zakopiańska 18
Distance:
Przedsiębiorstwo Wielobranżowe „ELEKTRO-HURT” Aleksander Winter Sp. z o.o.
Gniezno,
ul. Słoneczna 40a
Distance:
Additional information:
Information | Value |
---|---|
Updated: | 2024-07-26 11:17:38 |
Files to download: | |
External links: |
