Mini stycznik MCRC031ATWN
Information | Value |
---|---|
Supplier | ABB Sp. z o.o. (NN) |
Symbol | 1SAH220403R9900 |
GTIN(EAN) | 4013614547089 |
Price unit | piece |
Catalog price | 228,68 zł (185,92 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Net weight: | 235 g |
ETIM class: | Contactor relay |
Voltage type for actuating: | DC |
Rated operation current Ie, 400 V: | 4 A |
Connection type auxiliary circuit: | Screw connection |
Mounting method: | DIN rail |
Interface: | no |
Number of auxiliary contacts as normally closed contact: | 1 |
Number of auxiliary contacts as normally open contact: | 3 |
With LED indication: | no |
Suitable for manual operation: | no |
Rated control supply voltage DC: | 220 - 220 V |
Number of auxiliary contacts as normally closed contact, delayed switching: | 0 |
Number of auxiliary contacts as normally open contact, leading: | 0 |
Number of auxiliary contacts as change-over contact: | 0 |
Rated operation current: | 6 A |
Operating voltage AC 50 Hz: | 690 - 690 V |
Operating voltage AC 60 Hz: | 690 - 690 V |
Operating voltage DC: | 440 - 440 V |
Voltage type (operating voltage): | DC |
Rated switch current: | 6 A |
Width: | 45 mm |
Height: | 48 mm |
Depth: | 68 mm |
