Ogranicznik przepięć DEHNgate GFF TV DGA GFF TV
Information | Value |
---|---|
Supplier | DEHN Polska Sp. z o.o. |
Symbol | 909705 |
GTIN(EAN) | 4013364105706 |
Price unit | piece |
Catalog price | 838,42 zł (681,64 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
Information | Value |
---|---|
Gross weight: | 282,7 g |
Country of origin | Niemcy |
ETIM class: | Combined arrester for data networks/MCR-technology |
Max. continuous voltage DC: | 24 V |
Lightning impulse current (10/350 µs): | 2.5 kA |
Nominal discharge surge current (8/20): | 10 kA |
Nominal load current: | 2 A |
Voltage protection level: | 300 V |
Frequency: | 5.0 - 2400.0 MHz |
Mounting method: | DIN rail (top hat rail) 35 mm |
Connection 1: | F-Connector |
Pro-active thermo-control: | no |
With remote signalling contact: | no |
Explosion-tested version: | no |
Signal disconnection: | no |
Number of conductors (without earthing): | 1 |
Earthing via: | DIN rail (top hat rail) |
Assembly width: | 27 mm |
Degree of protection (IP): | IP30 |
