Ogranicznik przepięć DEHNgate GFF TV DGA GFF TV
| Information | Value |
|---|---|
| Supplier | DEHN Polska Sp. z o.o. |
| Symbol | 909705 |
| GTIN(EAN) | 4013364105706 |
| Price unit | piece |
| Catalog price | 838,42 zł (681,64 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 282,7 g |
| Country of origin | Niemcy |
| ETIM class: | Combined arrester for data networks/MCR-technology |
| Max. continuous voltage DC: | 24 V |
| Lightning impulse current (10/350 µs): | 2.5 kA |
| Nominal discharge surge current (8/20): | 10 kA |
| Nominal load current: | 2 A |
| Voltage protection level: | 300 V |
| Frequency: | 5.0 - 2400.0 MHz |
| Mounting method: | DIN rail (top hat rail) 35 mm |
| Connection 1: | F-Connector |
| Pro-active thermo-control: | no |
| With remote signalling contact: | no |
| Explosion-tested version: | no |
| Signal disconnection: | no |
| Number of conductors (without earthing): | 1 |
| Earthing via: | DIN rail (top hat rail) |
| Assembly width: | 27 mm |
| Degree of protection (IP): | IP30 |
